Microsoft Azure

This guide explains how RunWhen Local discovers Azure resources and AKS clusters via CloudQuery, and how you can control discovery scope, level‑of‑ detail (LoD), and authentication. Each configuration option is followed by a brief rationale so you can decide whether it is relevant to your environment.

AKS Cluster Discovery

Discovery methods

Method	Required Azure role(s)	Typical use‑case
Kubeconfig	Standard Kubernetes RBAC only	Rapid trials when you already possess a kubeconfig. No insight into backing Azure resources.
Service Principal (SP)	`Azure Kubernetes Service RBAC Reader`	Production‑grade installations. Same SP can also cover Azure resource discovery.
Managed Identity (MI)	`Azure Kubernetes Service RBAC Reader`	Secret‑less deployments on AKS or VMSS.

Why list each cluster? The Azure ARM API does not expose the Kubernetes API server endpoint. Specifying server: guarantees that the Kubernetes indexer can connect without additional look‑ups.

CODE

cloudConfig:
  azure:
    aksClusters:
      clusters:
        - name: aks‑cluster‑1               # Appears in generated SLX titles
          server: https://aks‑cluster‑1.hcp.eastus.azmk8s.io:443
          resource_group: rg‑aks‑1          # Links namespaces → resource group
          subscriptionId: sub‑aks‑1         # Optional when RG name is unique

If the subscriptions: array is omitted or empty, RunWhen Local passes an empty list to CloudQuery. CloudQuery then enumerates every subscription the credential can access. Include the array only when you must restrict discovery.

Namespace Level‑of‑Detail (LoD)

LoD determines how much data is retrieved from the Kubernetes or Azure API:

Value	Behaviour
`none`	Skip indexing — no SLX/SLI/run‑books produced
`basic`	Retrieve metadata; generate lightweight SLX/SLI
`detailed`	Retrieve all objects; generate run‑books

Precedence

Priority ▲	Location	Reason
1	Namespace annotation `config.runwhen.com/lod`	Allows application teams to opt‑in / opt‑out without changing workspace YAML.
2	Cluster block `defaultNamespaceLOD`	Lets platform owners set a safe default per cluster.
3	Workspace `defaultLOD`	Workspace‑wide fallback.

CODE

aksClusters:
  clusters:
    - name: aks‑cluster‑1
      defaultNamespaceLOD: basic    # Applies to all namespaces unless…

Azure Resource Discovery (CloudQuery)

CloudQuery inventories Azure resources so that RunWhen Local can match them to automation tasks (CodeBundles). Scoping the crawl lowers API consumption and speeds up runs.

Scoping options

Key	Scope	When it is useful
`subscriptions`	List of subscription objects	Limit discovery to specific subscriptions.
`resourceGroupLevelOfDetails`	Per resource group	Apply LoD on an RG basis (e.g. detailed for production RGs).
`includeTags`	Any ARM resource	Discover only resources that carry specific tags.
`excludeTags`	Any ARM resource	Omit resources that carry specific tags.

CODE

cloudConfig:
  azure:
    subscriptions:
      - subscriptionId: sub‑prod
        defaultLOD: basic
        resourceGroupLevelOfDetails:
          rg‑payments: detailed
      - subscriptionId: sub‑dev
        defaultLOD: none            # Ignore unless specifically overridden

If the subscriptions: array is absent, CloudQuery will automatically enumerate all subscriptions that the provided credential can access.

Authentication

Method	Advantages	Limitations
Service Principal (SP)	Portable; usable outside Azure; fine‑grained role assignment	Secret rotation required
Managed Identity (MI)	No secrets; automatic rotation	Only available on Azure resources

Creating a Service Principal

CODE

az account set --subscription <SUB_ID>
az ad sp create-for-rbac \
  --name runwhen-local-sp \
  --scopes /subscriptions/<SUB_ID> \
  --role Reader

Inline credentials (quick start)

CODE

cloudConfig:
  azure:
    subscriptionId: "<SUB_ID>"
    tenantId:       "<TENANT_ID>"
    clientId:       "<APP_ID>"
    clientSecret:   "<PASSWORD>"

Storing credentials in a secret (recommended)

CODE

kubectl create secret generic azure-sp \
  --from-literal=clientId=<APP_ID> \
  --from-literal=clientSecret=<PASSWORD> \
  --from-literal=subscriptionId=<SUB_ID> \
  --from-literal=tenantId=<TENANT_ID> \
  -n runwhen-local

CODE

cloudConfig:
  azure:
    spSecretName: azure-sp

Managed Identity

When neither inline credentials nor spSecretName are provided, the indexer falls back to Managed Identity. Ensure that the identity (either the pod’s user‑assigned MI or the node pool’s system‑assigned MI) has at least the Reader role on every subscription or resource group you wish to discover.

LoD Resolution Order (Quick Reference)

Namespace annotation config.runwhen.com/lod
resourceGroupLevelOfDetails inside a subscription object
Workspace‑level resourceGroupLevelOfDetails
Subscription‑level defaultLOD
Workspace defaultLOD

End‑to‑End Example

CODE

workspaceName: demo

defaultLOD: none   # Workspace fallback

cloudConfig:
  azure:
    # Authentication via secret
    spSecretName: azure-sp

    # Cluster list
    aksClusters:
      clusters:
        - name: aks-demo
          server: https://aks-demo.hcp.eastus.azmk8s.io:443
          resource_group: rg-aks-demo
          subscriptionId: sub-demo
          defaultNamespaceLOD: detailed

    # Subscription‑scoped discovery
    subscriptions:
      - subscriptionId: sub-demo
        defaultLOD: basic
        resourceGroupLevelOfDetails:
          rg-aks-demo: detailed

Execution flow:

The SP azure-sp authenticates.
CloudQuery is instructed to crawl sub-demo only.
Within that subscription, rg-aks-demo is crawled at detailed LoD; all other RGs default to basic.
The Kubernetes indexer connects solely to aks-demo and indexes every namespace at detailed LoD.

CloudQuery Plugin Version Matrix

CloudQuery source	Tested version
Azure	v9.4.0

Refer to the CloudQuery documentation for the full list of available tables.
